1PH Residential Split Air Conditioner 50HZ 240V Wall Mounted Ac Unit

    Buy cheap 1PH Residential Split Air Conditioner 50HZ 240V Wall Mounted Ac Unit from wholesalers

    Buy cheap 1PH Residential Split Air Conditioner 50HZ 240V Wall Mounted Ac Unit from wholesalers
    • Buy cheap 1PH Residential Split Air Conditioner 50HZ 240V Wall Mounted Ac Unit from wholesalers
    • Buy cheap 1PH Residential Split Air Conditioner 50HZ 240V Wall Mounted Ac Unit from wholesalers

    1PH Residential Split Air Conditioner 50HZ 240V Wall Mounted Ac Unit

    Ask Lasest Price
    Brand Name : DELTA
    Model Number : Residential Split Air Conditioner
    Certification : ISO9001
    Price : Negotiate
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 10000pcs/month
    Delivery Time : 20-25days
    • Product Details
    • Company Profile

    1PH Residential Split Air Conditioner 50HZ 240V Wall Mounted Ac Unit

    new Design Wall Mounted Type Air Condition/Residential Split Air Conditioner


    Features

    Plasma

    Plasma generate a high voltage electrostatic zone, absorb and eliminate dust, smoke and pollen particles. It also deodorizes air to remove tobacco odors, garbage smells.

    Mono & Multi Compatible

    The indoor unit is compatible for both mono and multi inverter system. Saving warehouse space and make warehouse management easier.

    Refrigerant Leakage Detect

    Indoor unit will show error code "EC" and stop automatically when refrigerant leakage is detected. this function can better protect compressor from being damaged by high temperature due to gas leakage.


    Product Paramenters
    MODEL
    09QB-K3DNB6B
    12QC-K3DNB6B
    18QD-K3DNB6B
    24QE-K3DNB6B
    Function
    Cooling/Heating
    Cooling/Heating
    Cooling/Heating
    Cooling/Heating
    Capacity-Cooling/BTU
    9000
    12000
    17981
    22000
    Capacity-Heating/BTU
    9600
    13000
    19005
    23000
    EER
    3.21
    3.21
    3.21
    3.21
    Power Supply
    1PH,220-240V,50HZ
    1PH,220-240V,50HZ
    1PH,220-240V,50HZ
    1PH,220-240V,50HZ
    Power Input-Cooling/W
    825
    1090
    1640
    2010
    Power Input-Heating/W
    775
    1050
    1540
    1870
    Rated Current-Cooling/A
    6.3
    6.9
    13.5
    11
    Rated Current-Heating/A
    6.9
    7.3
    13.8
    12
    Airflow Volume-Indoor
    560/490/430/330
    600/540/460/330
    850/800/700/570
    1100/1000/950/850
    Sound Pressure Level-Indoor
    39/36/32/25
    41/37/33/29
    47/43/39/35
    46/44/40/36
    Outline Dimension-W*H*D/mm
    790*275*200
    845*289*209
    970*300*224
    1078*325*246
    Package Dimension-W*H*D/mm
    866*357*271
    921*379*281
    948*645*420
    1029*750*458
    Net Weight/Gross Weight-Indoor/kg
    9~11
    11~13
    13.5/16.5
    16/19.5
    Sound Pressure Level-Outdoor
    49
    51
    55
    56
    Piping Connection-Gas/mm
    φ9.52
    φ9.52
    φ12
    φ16
    Piping Connection-Liquid/mm
    φ6
    φ6
    φ6
    φ6
    Outline Dimension-W*H*D/mm
    710*550*318
    710*550*318
    899*596*378
    955*700*396
    Package Dimension-W*H*D/mm
    774*607*351
    774*607*351
    948*645*420
    1029*750*458
    Net Weight/Gross Weight-Outdoor/kg
    28/30
    30/32
    41/44.5
    46/50.5
    Loading Quantity-40'GP/sets
    234
    225
    156
    118
    Loading Quantity-40'HQ/sets
    270
    261
    179
    131

    FAQ
    Q: Are you a manufacturer or trading company?
    A: We are a manufacturer that specialized in refrigeration equipment. Our products have abtained the CE.
    Q: What kind of delivery for the product?
    A: We can arrange the shipping by sea or by air.
    Q: How is your after-sales service?
    A: All the product is guarantee for one year.And we will supply the technical support after the warranty time. You can contact us24 hours each day online.
    Q: How can I get some samples?
    A: We welcome sample order to test and check quality. We can’t offer free sample, please pay the sample and express fee.
