1PH Residential Split Air Conditioner 50HZ 240V Wall Mounted Ac Unit

Ask Lasest Price
Brand Name :	DELTA
Model Number :	Residential Split Air Conditioner
Certification :	ISO9001
Price :	Negotiate
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	10000pcs/month
Delivery Time :	20-25days

Add to Cart

Product Details
Company Profile

1PH Residential Split Air Conditioner 50HZ 240V Wall Mounted Ac Unit

new Design Wall Mounted Type Air Condition/Residential Split Air Conditioner

Features

Plasma

Plasma generate a high voltage electrostatic zone, absorb and eliminate dust, smoke and pollen particles. It also deodorizes air to remove tobacco odors, garbage smells.

Mono & Multi Compatible

The indoor unit is compatible for both mono and multi inverter system. Saving warehouse space and make warehouse management easier.

Refrigerant Leakage Detect

Indoor unit will show error code "EC" and stop automatically when refrigerant leakage is detected. this function can better protect compressor from being damaged by high temperature due to gas leakage.

Product Paramenters

MODEL	09QB-K3DNB6B	12QC-K3DNB6B	18QD-K3DNB6B	24QE-K3DNB6B
Function	Cooling/Heating	Cooling/Heating	Cooling/Heating	Cooling/Heating
Capacity-Cooling/BTU	9000	12000	17981	22000
Capacity-Heating/BTU	9600	13000	19005	23000
EER	3.21	3.21	3.21	3.21
Power Supply	1PH,220-240V,50HZ	1PH,220-240V,50HZ	1PH,220-240V,50HZ	1PH,220-240V,50HZ
Power Input-Cooling/W	825	1090	1640	2010
Power Input-Heating/W	775	1050	1540	1870
Rated Current-Cooling/A	6.3	6.9	13.5	11
Rated Current-Heating/A	6.9	7.3	13.8	12
Airflow Volume-Indoor	560/490/430/330	600/540/460/330	850/800/700/570	1100/1000/950/850
Sound Pressure Level-Indoor	39/36/32/25	41/37/33/29	47/43/39/35	46/44/40/36
Outline Dimension-WHD/mm	790275200	845289209	970300224	1078325246
Package Dimension-WHD/mm	866357271	921379281	948645420	1029750458
Net Weight/Gross Weight-Indoor/kg	9~11	11~13	13.5/16.5	16/19.5
Sound Pressure Level-Outdoor	49	51	55	56
Piping Connection-Gas/mm	φ9.52	φ9.52	φ12	φ16
Piping Connection-Liquid/mm	φ6	φ6	φ6	φ6
Outline Dimension-WHD/mm	710550318	710550318	899596378	955700396
Package Dimension-WHD/mm	774607351	774607351	948645420	1029750458
Net Weight/Gross Weight-Outdoor/kg	28/30	30/32	41/44.5	46/50.5
Loading Quantity-40'GP/sets	234	225	156	118
Loading Quantity-40'HQ/sets	270	261	179	131

FAQ

Q: Are you a manufacturer or trading company?
A: We are a manufacturer that specialized in refrigeration equipment. Our products have abtained the CE.
Q: What kind of delivery for the product?
A: We can arrange the shipping by sea or by air.
Q: How is your after-sales service?
A: All the product is guarantee for one year.And we will supply the technical support after the warranty time. You can contact us24 hours each day online.
Q: How can I get some samples?
A: We welcome sample order to test and check quality. We can’t offer free sample, please pay the sample and express fee.
